Permobil F3 Corpus

Permobil F3 Corpus

The F3 CORPUS offers the smallest footprint of this redesigned series of front-wheel drive power wheelchairs. Its size and agility let users move quickly in and out of tight spaces like busy city streets and crowded areas like malls…or even parties. The platform has a lower, repositioned center of gravity, which greatly improves stability while traversing inclines or declines. With its fully independent suspension, the F3 provides a comfortable ride and allows users to navigate the obstacles of life.

The power of the F3 comes in its compact, yet stable footprint. This allows you greater maneuverability in your environment with the option to remove anti-tippers.

Resources

Category:

Additional information

Maximum User Weight

300 lbs (136 kgs)
Maximum Speed

6 mph (10km/h)
Driving Range

13 miles (21 km)
Base Width

24" (610 mm)
Base Length

36" (40" w/ anti-tippers)
Minimum Turning Radius

26.5" (673 mm)
Ground Clearance

3" (75 mm)
Drive Electronics

R-net 120A
Battery Type

Group 24 Gel
Group 34 Gel
Optional Seat Elevator

12" (300 mm)
Seat to Floor Height

17.5", 18.5", 19.5" (445, 470, 495 mm)
Power Tilt Options

0° – 50° Posterior
5º, 10°, 20° & 30° Anterior
Recline Options

85º-120° (manual)
85º-180° (power)
Legrest Elevation

85° – 170°
Armrest Pad Lengths

10", 13", 16" & 18"
Seat Widths

17-23" (2" increments)
Seat Depths

14-22" (1" increments)
Backrest Heights

20", 23" – 28" (1" increments)
Manufacturer

Permobil
